CE Certified High Efficiency Low Energy Consumption Food Lyophilization Equipment Freeze Dry Machine

CE Certified High Efficiency Low Energy Consumption Food Lyophilization Equipment Freeze Dry Machine

Nom De Marque:	LTPM China
Numéro De Modèle:	LTDG-séries
MOQ:	1 ensemble
Prix:	Négociable
Conditions De Paiement:	LC, T/T
Capacité à Fournir:	15 sets/mois

Les informations détaillées

Description du produit

Les informations détaillées

Lieu d'origine:

Chine

Certification:

Poids:

1200 kg

Nom de l'article:

Lyophilisateur

Secteur sec:

1,08 mètres carrés

Tray Area:

1,02 mètres carrés

Tout le volume de déshydratation:

15 kg/batch

espacement d'étagère:

70 millimètres

Mode de chauffage:

Mode de conduction

Système d'exploitation:

Écran tactile

Détails d'emballage:

Caisse en bois standard d'exportation

Capacité d'approvisionnement:

15 sets/mois

Mettre en évidence:

CE certified freeze dry machine

low energy consumption food lyophilizer

pharmaceutical freeze drying equipment

Description du produit

Vacuum freeze dryer is a processing equipment for heat and mass transfer of freeze-dried materials in a vacuum and low temperature environment. It is an interdisciplinary comprehensive technology. Freeze-drying requires technical support such as vacuum, refrigeration, heating, mechanical transmission, and automatic control. The application range of vacuum freeze-drying technology is very wide, as long as it is water-containing, non-corrosive substances can be made into freeze-dried products by freeze-drying technology, almost all agricultural and sideline products such as meat, poultry, eggs, aquatic products, vegetables, etc. Can be made into freeze-dried products. At present, freeze-drying technology is widely used in the food industry, biopharmaceutical industry, nanoscale materials, etc. The product processed by this technology is called freeze-dried food (fd food freeze-dried), which can maintain the color, aroma, taste, shape and nutritional components of the original food, and has a good rehydration effect.

Key Features

Economical design with high energy efficiency
Multiple heat source options: steam and electrical
Modular design for fast installation and short production cycles
Highly integrated components with compact footprint
Continuous automatic vacuum de-icing system with minimal temperature loss
Real-time precise temperature control for consistent product quality
Energy efficient operation with large freeze drying capacity
Rapid vacuum extraction reaching process requirements within 12 minutes
PLC automatic control system for optimal working conditions
Simple operation, easy maintenance, and reliable performance

Characteristics

Retain the original nutrition of the product
Dehydration thoroughly
Strong rehydration
Especially suitable for heat-sensitive substances

Application

Fruit
Vegetables
Pet food
Meat and Seafood
Condiments
Nutrition

Technical Specifications

Power	167Kw, 380V±10%, 50HZ, 3 Phase, 5 Wire
Vacuum Function	19.8kw
Refrigeration Function	92kw
Heating Function	55.5kw
Compressed Air	≥40L/min (P=0.5~0.8Mpa)
Cooling Water Quantity	≥50m³/h (T≤30℃, P=0.2-0.3Mpa)
Defrost Water Quantity	≥4000kg (T≥30℃, P=0.1-0.2Mpa)
Whole Volume	Dry chamber and Condenser: D=φ2100mm L=6650mm Freeze system vacuum system control system: L=2600mm W=2200mm H=2000mm Final dimension based on design
Structure	Split
Total Weight	15T (Approx.)
